SGDC-534BC

Technical Information & Function:
Width of Door (mm) Max: 1100
Weight of Door (kg) Max.: 85
Delay Action: No
Backcheck Function: Yes
Spring Strength Adjustable: No
Max. Open Angle: 180°
Hold - Open: No
Closing Speed Adjustment:

• Speed 1 : 180° - 15°
• Speed 2 : 15° - 0°

Applicable Temperature: -30°C - 40°C
Fire Door: Yes
Dimension of Main Body (mm):

• Length: 223
• Width: 44.5
• Height: 72

Weight (kg): 1.425
Passed Durability Test: 500,000 Cycles
